Product Model: Ballast-WL-811-BAC
- Product features:
1. WL - 811 die-casting aluminum shell, built-in WL1305-1 (thin CANBUS one-piece) in the circuit board;
2. All products potting process;
3. The working voltage 9 ~ 16 v, with reverse protection, open circuit protection, short circuit protection, the overpressure protection function;
4. The constant power output;
5. Using the environment temperature range - 40 ℃ ~ 85 ℃;
- Introduction
- Details
- Specification
Product features:
1. WL - 811 die-casting aluminum shell, built-in WL1305-1 (thin CANBUS one-piece) in the circuit board;
2. All products potting process;
3. The working voltage 9 ~ 16 v, with reverse protection, open circuit protection, short circuit protection, the overpressure protection function;
4. The constant power output;
5. Using the environment temperature range - 40 ℃ ~ 85 ℃;
6. Waterproof, shockproof, satisfies the requirement of automobile and motorcycle used.
Scope of application:
This product is suitable for automobile, motorcycle headlamps modified.
1. WL - 811 die-casting aluminum shell, built-in WL1305-1 (thin CANBUS one-piece) in the circuit board;
2. All products potting process;
3. The working voltage 9 ~ 16 v, with reverse protection, open circuit protection, short circuit protection, the overpressure protection function;
4. The constant power output;
5. Using the environment temperature range - 40 ℃ ~ 85 ℃;
6. Waterproof, shockproof, satisfies the requirement of automobile and motorcycle used.
Scope of application:
This product is suitable for automobile, motorcycle headlamps modified.
Model | WL-811-BAC |
Specification | 12V35W CANBUS |
Terminal | AMP |
Color | Black |
Input Voltage | 9~16VDC |
Start Current | 3.60±0.50A |
Stable Input Current | 3.60±0.15A |
Input High Voltage Protection | 17.5-18V |
Reverse connect protection | Test Reverse connect |
Output Open Circuit Protection | Automatically stop working within 2s while open circuit |
Output Short Circuit Protection | Automatically stop working within 3s while short circuit |
Rated Output Power | 35±1.5W |
Output Frequency | 250±10%Hz |
Air Striking Distance | 6.5-7mm |
Working Efficiency | ≥80% |
Working Temperature | -40℃～85℃ |
Lifetime | ≥3000 hours |
